Nitrate nitrogen(NO3-N)analyzer UC1000/lyter-NO3
product details

Typical applications
Continuous monitoring of organic load during sewage treatment and online real-time monitoring of inlet and outlet water quality in sewage treatment plants;
Continuous online monitoring of surface water, industrial wastewater discharge, and fishery wastewater discharge
FEATURES
Probe direct immersion measurement without sampling and preprocessing;
No need for chemical reagents, secondary pollution;
Short response time, capable of continuous measurement;
The sensor has an automatic cleaning function, which can reduce maintenance.
Continuous monitoring of organic load during sewage treatment and online real-time monitoring of inlet and outlet water quality in sewage treatment plants;
Continuous online monitoring of surface water, industrial wastewater discharge, and fishery wastewater discharge
FEATURES
Probe direct immersion measurement without sampling and preprocessing;
No need for chemical reagents, secondary pollution;
Short response time, capable of continuous measurement;
The sensor has an automatic cleaning function, which can reduce maintenance.
UC1000-UV Controller Main Technical Parameter
Display : LCD ,240*180 graphic dot
Language selection: English, Simplified Chinese
output: 2-channel isolated 0/4~20mA, 500Ω Max
communication: MODBUS RS485 protocol
Data recording: Built-in storage function
Relay control: 250VAC 5A Max
Protection grade: IP66
Power supply: 100-240VAC, 50/60Hz, 24VDC, optional
Measurement range: 0.1~100.0mg/L ( 1mm ),0.1~50.0mg/L ( 2mm ),0.1~25.0mg/L ( 5mm )
Measurement accuracy: ± 5%±0.5mg/l
Resolution: 0.01 mg/L
Minimum detection limit: 0.1 mg/L
Measurement accuracy: ± 5%±0.5mg/l
Resolution: 0.01 mg/L
Minimum detection limit: 0.1 mg/L
Automatic SS compensation function
The cleaning function comes with a scraper cleaning function, and the interval can be adjusted
Communication output: RS485
Working temperature: 0-45 ℃
Storage temperature: -15~50 ℃
Pressure range: 0~0.4Mpa
Body material SUS316L (standard), titanium alloy (optional)
The standard cable length is 10m, and other options are available
Protection level: IP68
The cleaning function comes with a scraper cleaning function, and the interval can be adjusted
Communication output: RS485
Working temperature: 0-45 ℃
Storage temperature: -15~50 ℃
Pressure range: 0~0.4Mpa
Body material SUS316L (standard), titanium alloy (optional)
The standard cable length is 10m, and other options are available
Protection level: IP68
Product weight: approximately 3.2kg
Product dimensions: 69mm * 365/368/413mm (D * L),
